מפרט טכני מלא
שילדה
Hydro Formed T6 6061 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts
מזלג קדמי
Fox Float 38, Factory 29", 180mm Travel, 44mm Offset with Grip 2 Damper, Tapered Steerer, Kashima Coating, 110mm x 15mm Boost, E-Thru Axle
בולם אחורי
Fox Float X2, Factory, independently adjustable Compression and Rebound damping, Kashima coating
מנוע
Bosch Performance Line CX, 85Nm maximum torque, 250W nominal power. Features four power settings
בטריה
Bosch PowerTube 750Wh internal, perfectly integrated into the frame with an intuitive lockable mechanism for easy removal
ידיות הילוכים
SRAM AXS Pod, 2 Button MMX, 12 Speed
מעביר אחורי
SRAM GX AXS T-Type 12 Speed
קראנק
Race Face Affect E-Bike, 165mm, ISIS with T-Type Direct Mount 36T for Bosch Performance Line CX, Black
קסטה
SRAM XS-1275 T-Type Eagle, 10-52, 12 Speed
שרשרת
SRAM GX T-Type Eagle, 12 Speed
מעצורים
SRAM Code RSC, 4 Piston with Sintered Metal Pads, 220mm Disc
גלגלים
DT Swiss Hybrid HX1700
צמיגים
Maxxis Assigai WT, 29"x2.5" 120TPI, EXO + Sidewall Protection, 3C MaxxGrip (F)/Maxxis Assigai WT, 27.5" x 2.5" 120TPI, Double Casing, 3C MaxxGrip ®
אוכף
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail
מוט אוכף
Crank Bro High-Line 3, 30.9mm, 150mm Travel, High-Line Ball Socket Remote Lever
כידון
Race Face Turbine R, 35mm Rise, 35mm Bar Bore, 800mm Wide
מוט כידון
Race Face Atlas, 35mm Bar Bore, 35mm Extension
מיסבי היגוי
FSA No. 55/35 Orbit 1.5 ZS, 1.8" Lower and 1 1/8" Upper Sealed Cartridge Bearings
גיאומטריה
.webp)
|
FRAME SIZE |
Small |
Medium |
Large |
Extra Large |
|
A – REACH (mm) |
431 |
456 |
481 |
506 |
|
B – STACK (mm) |
628.7 |
640.5 |
652.3 |
663.2 |
|
C – HEAD ANGLE (° degrees) |
64.6 (64) |
64.6 (64) |
64.6 (64) |
64.6 (64) |
|
D – SEAT ANGLE (° degrees) |
77.5 |
77.3 |
77.1 |
76.9 |
|
E – BB HEIGHT (mm) |
341.9 (333.9) |
341.9 (333.9) |
341.9 (333.9) |
341.9 (333.9) |
|
F – WHEELBASE (mm) |
1211.6 |
1242.1 |
1272.6 |
1302.7 |
|
G – REAR CENTRE (mm) |
450.4 |
450.4 |
450.4 |
450.4 |
|
H – STANDOVER HEIGHT (mm) |
741 |
741 |
741 |
741 |
|
I – SEAT TUBE LENGTH (mm) |
395 |
420 |
445 |
470 |
|
J – HEAD TUBE LENGTH (mm) |
114 |
127 |
140 |
152 |
